Specifications and options for CSA-108
Use CSA-108 as the visual reference, then confirm capacity, size, heater voltage, wood finish, glass direction, MOQ, packing, and document needs before quotation.
| Model / SKU | CSA-108 |
|---|---|
| Product type | Outdoor sauna cabin |
| Use setting | Outdoor |
| Capacity | 2-8 person |
| Wood / finish | Solid wood construction; species and finish confirmed from project requirements |
| MOQ | Confirmed by order quantity, selected configuration, and destination before quotation |
| Quotation basis | Selected configuration, heater route, destination, packing, and project requirements confirmed before quotation |
| Reference | CSauna factory catalog record |
| Confirmation items | Dimensions, packing, material details, and order drawings are confirmed before production. |
Use CSA-108 as the visual model reference. Final size, bench layout, heater, glass, voltage, packing, and document route are locked after the approved drawing.
Known vs. confirm before production
| Recorded for review | Model title, model code, MOQ reference, price band, product type, and image set. |
|---|---|
| Confirm with buyer | Final dimensions, material grade, heater option, glass/door direction, packing size, loading plan, labels, accessories, and destination requirements. |
| Approval step | CSauna confirms the final drawing, quotation, packing details, and order record before production starts. |
RFQ checklist for this model
- Target quantity and whether this is sample, distributor, or project order.
- Preferred size, wood/finish, heater type, voltage, and control option.
- Destination port or delivery country for freight and compliance review.
- Packaging, logo/private label, spare parts, and document requirements.
- Any site drawing, showroom reference, or installation constraint.
Model views for buyer review
Send us this model code
CSA-108 | bennett@csauna.com | WhatsApp / Phone: +86 180 7047 6405
Power and voltage
CSA-108 2-8 person configurable heater planning
Buyer decision sheet
CSA-108 2-8 Person Custom Outdoor Wood Sauna Room
CSA-108 is a configurable outdoor-room reference rather than one fixed stock size. A useful quotation must turn the requested 2-8 person capacity into a controlled drawing, material schedule, heater file, and packing plan. The buyer should therefore approve the following points together instead of selecting capacity from the title alone.
Capacity and drawing
State the expected seated users, exterior footprint, internal clear space, bench length and levels, door swing, glass direction, and entry side. A larger capacity changes heater sizing, bench support, panel count, crate volume, and installation access, so the approved drawing becomes the production reference.
Wood and finish
Separate the interior wood, exterior cladding, bench material, and exposed trim in the quote file. Confirm species, grade direction, knot tolerance, surface tone, oil or stain route, exterior weather protection, adhesive requirement, and an approved color sample before repeat production.
Voltage and heater power
Give the destination country, site supply, phase, and preferred controller. CSauna can plan around 110-120V or 208/220-240V routes for North America, 220-240V or 380-415V routes for Europe, and 220-240V routes commonly used in Southeast Asia and Oceania. Final heater kW follows room volume, glass area, insulation, climate, and recovery-time target.
Site handoff
Provide the base type, drainage approach, outdoor exposure, snow or rain condition, service clearance, cable entry, ventilation expectation, and delivery path. Confirm whether the room arrives as panels or larger modules and whether local lifting equipment or restricted-access handling is required.
Packing and evidence
Current catalog direction is MOQ 1 set for a standard sample; OEM branding, custom finish, and packaging can carry separate minimums. Request the panel or module packing plan, glass protection, crate dimensions, CBM, labels, manual language, wiring diagram, heater documents, production photos, and final inspection record.
Send with the quote request
- Target capacity and exterior size
- Bench and door layout
- Interior and exterior wood schedule
- Destination voltage, phase, and controller
- Heater kW calculation basis
- Packing method, port, and delivery access
Certification scope is confirmed against the selected heater, controls, glass, and destination market. CE, ETL, UL, or other evidence should not be assumed from the model image alone; list the exact documents required in the CSA-108 inquiry file.
